A humidifier is a device that increases humidity (moisture) in a single room or an entire building. In the home, point-of-use humidifiers are commonly used to humidify a single room, while whole-house or furnace humidifiers, which connect to a home's HVAC system, provide humidity to the entire house. Medical ventilators often include humidifiers for increased patient comfort. Large humidifiers are used in commercial, institutional, or industrial contexts, often as part of a larger HVAC system.
Maps, Directions, and Place Reviews
Overview
Low humidity may occur in hot, dry desert climates, or indoors in artificially heated spaces. In winter, especially when cold outside air is heated indoors, the humidity may drop to as low as 10-20%. This low humidity can cause adverse health effects, by drying out mucous membranes such as the lining of the nose and throat, and can cause respiratory distress. The low humidity also can affect wooden furniture, causing shrinkage and loose joints or cracking of pieces. Books, papers, and artworks may shrink or warp and become brittle in very low humidity.
In addition, static electricity may become a problem in conditions of low humidity, destroying semiconductor devices, causing static cling of textiles, and causing dust and small particles to stick stubbornly to electrically charged surfaces.
Overuse of a humidifier can raise the relative humidity to excessive levels, promoting the growth of dust mites and mold, and can also cause hypersensitivity pneumonitis (humidifier lung). A relative humidity of 30% to 50% is recommended for most homes. A properly installed and located hygrostat should be used to monitor and control humidity levels automatically, or a well-informed and conscientious human operator must constantly check for correct humidity levels.
Honeywell Oscillating Ceramic Heater Video
Industrial humidifiers
Industrial humidifiers are used when a specific humidity level must be maintained to prevent static electricity buildup, preserve material properties, and ensure a comfortable and healthy environment for workers or residents.
Static problems are prevalent in industries such as packaging, printing, paper, plastics, textiles, electronics, automotive manufacturing and pharmaceuticals. Friction can produce static buildup and sparks when humidity is below 45% relative humidity (RH). Between 45% and 55% RH, static builds up at reduced levels, while humidity above 55% RH ensures that static will never build up. The American Society of Heating, Refrigerating and Air Conditioning Engineers (ASHRAE) has traditionally recommended a range of 45-55% RH in data centers to prevent sparks that can damage IT equipment. Humidifiers are also used by manufacturers of semiconductors and in hospital operating rooms.
Printers and paper manufacturers use humidifiers to prevent shrinkage and paper curl. Humidifiers are needed in cold storage rooms to preserve the freshness of food against the dryness caused by cold temperatures. Art museums use humidifiers to protect sensitive works of art, especially in exhibition galleries, where they combat the dryness caused by heating for the comfort of visitors during winter.
Portable humidifiers
A "portable" humidifier may range in size from a small tabletop appliance to a large floor-mounted unit. The water is usually supplied by manually filling the unit on a periodic basis.
Evaporative humidifiers
The most common portable humidifier, an "evaporative", "cool moisture", or "wick humidifier", consists of just a few basic parts: a reservoir, wick and fan.
The wick is made of a porous material that absorbs water from the reservoir and provides a larger surface area for it to evaporate from. The fan is adjacent to the wick and blows air onto the wick to aid in the evaporation of the water. Evaporation from the wick is dependent on relative humidity. A room with low humidity will have a higher evaporation rate compared to a room with high humidity. Therefore, this type of humidifier is partially self-regulating; as the humidity of the room increases, the water vapor output naturally decreases.
These wicks become moldy if they are not dried out completely between fillings, and become saturated with mineral deposits over time. They regularly need rinsing or replacement; if this does not happen, air cannot pass through them, and humidifier stops humidifying the area it is in and the water in the tank remains at the same level.
Natural humidifiers
One type of evaporative humidifier makes use of just a reservoir and wick. Sometimes called a "natural humidifier", these are usually non-commercial devices that can be assembled at little or no cost. One version of a natural humidifier uses a stainless steel bowl, partially filled with water, covered by a towel. A waterproof weight is used to sink the towel in the center of the bowl. There is no need for a fan, because the water spreads through the towel by capillary action and the towel surface area is large enough to provide for rapid evaporation. The stainless steel bowl is much easier to clean than typical humidifier water tanks. This, in combination with daily or every other day replacement of the towel and periodic laundering, can control the problem of mold and bacteria.
Houseplants may also be used as natural humidifiers, since they evaporate water into the air through transpiration. Care must still be taken to prevent bacteria or mold in the soil from growing to excessive levels, or from dispersing into the air.
Vaporizers
A vaporizer (steam humidifier, warm mist humidifier) heats or boils water, releasing steam and moisture into the air. A medicated inhalant can also be added to the steam vapor to help reduce coughs. Vaporizers may be more healthful than cool mist types of humidifiers because steam is less likely to convey mineral impurities or microorganisms from the standing water in the reservoir. However, boiling water requires significantly more energy than other techniques. The heat source in poorly designed humidifiers can overheat, causing the product to melt, leak, and start fires.
Impeller humidifiers
An impeller humidifier (cool mist humidifier) uses a rotating disc to fling water at a diffuser, which breaks the water into fine droplets that float into the air. The water supply must be kept scrupulously clean, or there is a risk of spreading bacteria or mold into the air. These types of humidifiers are usually noisier than others.
Ultrasonic humidifiers
An ultrasonic humidifier uses a ceramic diaphragm vibrating at an ultrasonic frequency to create water droplets that silently exit the humidifier in the form of cool fog. Usually the mist gets forced out by a tiny fan, while some ultra mini models have no fans. The models without fans are meant mainly for personal use. Ultrasonic humidifiers use a piezoelectric transducer to create a high frequency mechanical oscillation in a film of water. This forms an extremely fine mist of droplets about one micron in diameter, that is quickly evaporated into the air flow.
Unlike the humidifiers that boil water, these water droplets will contain any impurities that are in the reservoir, including minerals from hard water (which then forms a difficult-to-remove sticky white dust on nearby objects and furniture). Any pathogens growing in the stagnant tank will also be dispersed in the air. Ultrasonic humidifiers should be cleaned regularly to prevent bacterial contamination from being spread throughout the air.
The amount of minerals and other materials can be greatly reduced by using distilled water. Special disposable demineralization cartridges may also reduce the amount of airborne material, but the EPA warns, "the ability of these devices to remove minerals may vary widely." The mineral dust may have negative health effects. Wick humidifiers trap the mineral deposits in the wick; vaporizer types tend to collect minerals on or around the heating element and require regular cleaning with vinegar or citric acid to control buildup.
Fixed-installation humidifiers
For buildings with a forced-air furnace, a humidifier may be installed into the furnace. They can also protect wooden objects, antiques and other furnishings which may be sensitive to damage from overly dry air. In colder months, they may provide modest energy savings, since as humidity increases, occupants may feel warm at a lower temperature.
Bypass humidifiers are connected between the heated and cold air return ducts, using the pressure difference between these ducts to cause some heated air to make a bypass through the humidifier and return to the furnace.
Any humidifiers should usually be disabled during the summer months if air conditioning is used; air conditioners partially function to reducing indoor humidity, and having a humidifier continue to operate will waste significant amounts of energy.
Drums
Drum style (bypass) uses a pipe to bring water directly to a reservoir (a pan) attached to the furnace. The water level in the pan is controlled by a float valve, similar to a small toilet tank float. The wick is typically a foam pad mounted on a drum and attached to a small motor; hot air enters the drum at one end and is forced to leave through the sides of the drum. When the hygrostat calls for humidity, the motor is turned on causing the drum to rotate slowly through the pan of water and preventing the foam pad from drying out.
For the latter reason especially, drum-style humidifiers should always be turned off at the water supply during summer (air conditioning) months, and should always be used with high quality furnace air filters (MERV ratings as high as possible to ensure small numbers of mold spores reaching the humidifier pan) when the water supply is turned on.
Disc wheels
A disc wheel style (bypass) is very similar in design to the drum style humidifiers; this type of furnace humidifier replaces the foam drumming with a number of plastic discs with small grooves on both sides. This allows for a very large evaporative surface area, without requiring a great deal of space. Unlike the drum style humidifiers, the disc wheel does not need regular replacement.
Bypass flow-through
Bypass flow-through style (bypass - also known as "biscuit style" or many other, similar variant names) uses a pipe to bring water directly to an electrically controlled valve at the top of the humidifier. Air passes through an aluminum "biscuit" (often called a pad; the term "biscuit" emphasizes the solid rather than foamy form) which is similar to a piece of extremely coarse steel wool. The biscuit has a coating of a matte ceramic, resulting in an extremely large surface area within a small space. When the hygrostat calls for humidity, the valve is opened and causes a spray of water onto the biscuit. Hot air is passed through the biscuit, causing the water to evaporate from the pad and be carried into the building.
Spray mist
Spray mist type uses a pipe, usually a small plastic tube, to bring water directly to an electrically controlled valve (atomizer-this forces the water through a tiny orifice causing it to break up into tiny particles) in the humidifier. Water mist is sprayed directly into the supply air, and the mist is carried into the premises by the air flow.
Natural humidifiers with non-electric, hydropneumatic control
Evaporator with non electric hydropneumatic control
Tasks of the functions: o The hydropneumatic control makes it possible to humidify every room regardless of a heat source or a fan. o By reversing the humidification process, i.e. through moisture, which slides downward into the room, this causes a longer dwell time of the humidity in the room. o Also the filling process of the evaporation surface runs from top to bottom. This makes it possible to fill up the surface with water, by flooding and prevents contamination, because the water tank is without direct contact to the evaporation surface and allows fresh water to flow. Here the evaporation surface does not act as a filter for the lime, it is used to evenly distribute the water.
Explanation: Water runs from the top over the surface (1), and the hydropneumatic controller takes over control of the water flow. The water, which runs over the surface, is collected in a catch basin (2). In order to make running fresh water out from a closed tank (5), it requires air. The water pressure suctions the air from the catch basin via a hose (3). Here the dripping water can close the hose and thereby, through under-pressure in the water tank (5), stops running out of the water tank. The filling process is stopped immediately and is restarted in relation to the humidity of the air. Contamination is once more suppressed, because dripped water immediately evaporates in the lime separator and, if necessary, in the humidity poster.
Humidification posters:
In humidification posters, the evaporation surface is spread into a large quantity of air. In accordance with the moisture content in the air, air is able to absorb moisture. The air mass, which slightly cools, becomes greater and it starts to drop. The air recirculation as a result of this technique is adapted to the humidity of the air. In other words, this occurs quickly with dry air and slowly with moist air and is self-regulating.
Process: The evaporation surface (1) suctions water out of the capillary basin (6), puts the capillary pump (8) for the flooding process in action and quickly fills the surface from top to bottom. Then it drips into the catch basin (2). The water evaporates and sets the air circulation into motion. The drained water closes the hose (3) below. Here, air which flows via pipe into the water tank (5) is interrupted. The water in the tank can no longer flow out because under-pressure occurs. The residual water in the capillary basin (6), on the upper part, is evaporated by the evaporation surface (1). The residual water in the catch basin (2), on the bottom, is suctioned out by the lime separator (7) and evaporated. As soon as the catch basin is empty, air then flows again through the hose (3); water from the tank flows back to the capillary basins (6) and thereby begins the process again. The alternating filling levels for the catch and capillary basins suppress the creation of germs.
Additional types
Additional types include non-bypass flow-through (fan augmented), steam, impeller or centrifugal atomizer, and under duct designs.
Problems and health risks
The USEPA provides detailed information about health risks as well as recommended maintenance procedures. If the tap water contains a lot of minerals (also known as "hard water") then the ultrasonic or impeller humidifiers will produce a "white dust" (calcium is the most common mineral in tap water), which usually spreads over furniture, and is attracted to static electricity generating devices such as CRT monitors. The white dust can be prevented by using distilled water or a demineralization cartridge in ultrasonic humidifiers.
In addition, a stuck or malfunctioning water supply valve can deliver large amounts of water, causing extensive water damage if undetected for any period of time. A water alarm, possibly with an automatic water shutoff, can help prevent this malfunction from causing major problems.
Common humidifier brands
Listed alphabetically
- Boneco
- Crane
- Heaven Fresh
- Holmes
- Honeywell
- Pure Guardian
- Vicks
- Vornado
- Winix
